CE, RoHS, UL compliant
120V
California Title 20 and 24 tested and approved (HVI-916)
Two Sizes to conveniently fit in the existing HVAC return.
20″x30″ Or 20″x36″
Paired with the CVT Filtered Free Cooling and or CVT CentraFlow – Filtered Fresh Air Systems (No need to open doors or windows, keeping your home secure).
(This system can also be installed as a stand alone whole house fan, by finding a convenient spot in the ceiling, and not attaching to the HVAC system)
20″ ecm 3800 cfm fan motor flush mount
Easy install duct plate compatible with 14”, 16”, 18” & 20” collars
2 – Stability brackets
Spring return actuated damper –
When CVT GCF is On, the damper closes off the HVAC return duct, while keeping the Fan to the attic open.
When CVT GCF is Off, the damper closes and seals off the Fan to the attic, while keeping the HVAC return duct open.
(This keeps attic air and debris from entering the home unlike most whole house fans.)
CVT Control Board
CVT Wi-Fi App (turns on from anywhere)
Due to its low wattage use, it can run on a small generator
Extremely Efficient
Energy Management
Easy Installation
Speed control wall switch
Indoor temperature sensor
5 Year Limited Warranty
Optional Upgrade Items:
R-8 Insulated
Carbon Monoxide Sensor
Refrigerant Sensor
- Silencer kit- for directional airflow Includes:
4ft 20” R8 Flex
Lid collar
Extended wiring
Mounting straps & Mounting brackets
- Return Air Grill (Egg Crate Style)
We recommend products be installed by a licensed contractor.
Follow all Federal and Local building codes.
